McKeown—cervical anastomosis in minimally invasive esophagectomy
Brief Report

McKeown—cervical anastomosis in minimally invasive esophagectomy

Flavio Roberto Takeda^, Rubens Antonio Aissar Sallum^, Felipe Alexandre Fernandes^, Ivan Cecconello^

Department of Gastroenterology, Digestive Surgery Division, Hospital das Clínicas HCFMUSP, Faculdade de Medicina, Universidade de São Paulo, São Paulo, Brazil

^ORCID: Flavio Roberto Takeda, 0000-0001-7338-922X; Rubens Antonio Aissar Sallum, 0000-0003-1823-0042; Felipe Alexandre Fernandes, 0000-0001-7890-370X; Ivan Cecconello, 0000-0002-3535-4170.

Correspondence to: Flavio Roberto Takeda, MD, PhD, FACS. Department of Gastroenterology, Digestive Surgery Division, University of São Paulo Medical School, Av. Dr. Enéas de Carvalho Aguiar 255, São Paulo, SP, CEP: 05403-000, Brazil. Email:

Abstract: Esophagectomy is the preferred treatment in advanced esophageal cancer, but the location of the anastomosis after esophagectomy is debatable. Here, we discuss leakage rates between cervical or intrathoracic anastomosis and complications related to fistulae. The aim of this review article is to describe the McKeown procedure with step-by-step cervical anastomosis. We also update evidence in the literature and discuss the experience of our institution. We report our experience with the cervical anastomosis in minimally invasive esophagectomy and performed a brief review of patients operated in our institution mainly related the rate of cervical fistulas. From 2009 to 2019, more than 345 esophagectomy with cervical anastomosis were performed, and fistula was diagnosed in 46 (13.3%). The spontaneous preferred locations of the liquid drainage after leakage were cervical (38/46, 82.6%), upper mediastinum (4/46, 8.7%), and mediastinum with mediastinitis (4/46, 8.7%). The main risk factors for anastomosis leak are gastric tube perfusion, obesity, heart failure, coronary heart disease, vascular disease, smoking, and cervical anastomosis. The literature shows different opinions and results based on surgeon and center experiences. The McKeown procedure is a feasible, standardized, and secure procedure. Anastomosis leak increases the morbidity and mortality and the frequency of anastomotic leakage in the literature. The rate is around 10% with low mortality.

Keywords: Esophagectomy; cervical anastomosis; McKeown; complications

Received: 23 January 2021; Accepted: 19 March 2021; Published: 25 June 2022.

doi: 10.21037/aoe-21-11


McKeown esophagectomy is a well described procedure with right thoracotomy, upper abdominal laparotomy, and cervical anastomosis by left cervicotomy. In Brazil, most esophageal carcinoma cases are squamous cell type; 77% of esophageal carcinomas in Brazil. These cases require an extended proximal margin of the esophagus justifying the cervical location of the anastomosis. In the last 15 years, our institution has moved to minimal invasive procedures for thoracic tumor resection and lymphadenectomy via thoracoscopic approaches (1). This has reduced the morbidity from 62% to 42.5% (2). The transhiatal approach was introduced to Brazil 1977 by Prof. Henrique Walter Pinotti, and the absence of thoracotomy reduced the respiratory complication from 28% to 12% versus the thoracoscopic approach. Over 40 years, we experienced a reduction of morbidity and complications related to the magnitude of the procedure. We always performed cervical anastomosis in systematic way; unfortunately, we noted the same rate of anastomotic leakage (around 15%) (3).

The McKeown procedure involves three parts: (I) the thoracic part is mostly esophageal dissection with inferior mediastinal, infra-carinal, bilateral peri-bronchial, para-tracheal and recurrent lymphadenectomy (extended two field dissection), (II) left cervical incision involves dissection of cervical esophagus and cervical anastomosis; (III) the abdominal part is after gastric mobilization (preservation of main vessels from the great curvature of stomach) and proceeds the lymphadenectomy around the common hepatic artery, proper hepatic artery, and left gastric vessels. Finally, gastroplasty is performed with proximal gastrectomy and a thin gastric tube. We then perform a gastric pull-up through the posterior mediastinum to cervical location after left cervicectomy. The location of the esophagogastric anastomosis is correlated to step 1. Extension of oncological margins is important in resection particularly in middle esophageal squamous cell carcinoma. The proximal margin requires cervical location anastomosis after esophagectomy. The Surgeon’s option of surgical approaches for esophagectomy is mainly based on his/her experienced related with post-operative complications. Several techniques have been described for cervical anastomosis such as hand-sewn, circular stapled, linear stapled, isoperistaltic, or anisoperistaltic; however, none of these is superior one.

Methods and patients

Ethical consideration

All procedures performed in this study were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patients.


The patient was placed in a prone position after peridural catheter anesthesia and a selective intubation of the left source bronchus. Five trocars were positioned as shown in Figure 1. The first 12 mm was introduced in the lower limit of the right scapula and the others were placed under direct vision and after using positive intrathoracic pressure of 8 mmHg CO2. Thus, four more trocars (two 10 mm and two 5 mm) were positioned—four of them along a semicircular line going from the medial edge of the scapula to the right posterior costal margin. The fifth trocar was positioned close to the column at the midpoint of this line (Figure 1).

Figure 1 Trocar placement by transthoracic esophagectomy by thoracoscopy for patients with esophagogastric junction adenocarcinoma. (A) 10 mm exchanger on the posterior hemiescapular line in the penultimate intercostal space, (B) 10 mm exchanger on the posterior axillary line 10 cm below the scapula, (C) 5 mm exchanger 5 cm from the column close to the lower edge of the scapula, (D) exchanger of 12 mm posterior axillary line and lower edge of the scapula, (E) exchanger of the 5 mm hemi-scapular line.

Infra-carinal dissection

The esophagus and lower periesophageal lymph node stations were dissected including the periaortic and supradiaphragmatic pericardia. Following the dissection, the right and left infracarinal lymph nodes were removed exposing the right and left bronchus at their origin in the carina (Figure 2).

Figure 2 Final aspect after infra-carinal lymphadenectomy using transthoracic esophagectomy by thoracoscopy for patients with esophageal cancer. (A) Left pulmonary vein, (B) right pulmonary vein, (C) left main bronchus, (D) right main bronchus, and (E) carina.

This was followed by isolation and sectioning via a mechanical suture of the azygos vein stem with a 60-mm endoscopic mechanical stapler with a vascular charge device and dissection towards the upper third of the thoracic esophagus. There was concern about clipping the thoracic duct at its origin near the right diaphragmatic pillar and near the intercostal vessels to avoid post-operative chylothorax.

Supra-carinal dissection

The proximal esophagus and supra-carinal periesophageal lymph node stations were dissected including para-tracheal and recurrent stations. The final aspect is demonstrated in Figure 3.

Figure 3 Final aspect after supra-carinal lymphadenectomy using transthoracic esophagectomy by thoracoscopy for patients with esophageal cancer. (A) Left main bronchi, (B) right main bronchi, (C) left paratracheal space, (D) right paratracheal space, (E) left recurrent space and (F) right recurrent space.

After complete dissection of the thoracic esophagus, the thoracic drain was positioned through the orifice of the most distal trocar. This followed by closing the ports and repositioning the patient in the horizontal supine position; the face was turned to the right side for left cervicectomy.

The stomach was liberated at the great curvature preserving the vessels from the gastroepiploic vessels. The small curvature was dissected by ligating the left gastric vessels. Gastroplasty (making the isoperistaltic gastric tube) was performed with manual staplers. We began stapling in the antrum via the lesser curvature and moved towards the greater curvature. We made a slim gastric tube to create an anastomosis in the cervical esophagus and emptied it properly.

The abdominal part of the lymphadenectomy was performed around the arteries of the liver as well as common hepatic artery, left gastric artery, and splenic vessels. The vein and left gastric artery at the origin were ligated.

The abdominal part was performed via the “hand-assisted” technique (laparoscopic dissection and stapling by small right subcostal incision). Cervical procedures were similar to those described in open transhiatal esophagectomy.

A cervical incision was made along the anterior border of the left lower sternocleidomastoid parallel to the clavicle. The cervical esophagus was identified after dissection of the cervical structures. After this stage, the esophagus was completely mobilized, and we performed dissection. The cervical esophagus was divided and a nasogastric tube was attached to the distal esophagus to guide the route of the reconstruction with the gastric tube.

Cervical anastomosis

The digestive track was reconstructed with esophagogastric latero-cervical anastomosis with mechanical stapling and re-enforcement with separate prolene 3.0 points. This was followed by cervical drainage with a thin Penrose drain, platysma layer closure, subcutaneous tissue, and skin. No omental patch or device was used to avoid anastomotic leakage (Figure 4).

Figure 4 Cervical anastomosis. (A) Lateral stapler anastomosis, (B) top lateral stapled anastomosis, (C) re-enforcement, and (D) final aspect.

Evaluation of anastomotic integrity

During the cervical anastomosis, a nasoenteric tube was allocated after the pylorus (laparoscopically assisted); eight days later, we performed an X-ray contrasted swallow ionic-liquid-contrast (no barium) as shown in Figure 5.

Figure 5 Contrast dynamic X-ray with ionic liquid contrast. Red arrows demonstrated the cervical anastomosis integrity without leakage.


Between 2009 and 2019, more than 345 esophagectomy cases with cervical anastomosis were performed, and fistula was diagnosed in 46 of them (13.3%). The spontaneous preferred locations of the liquid drainage after leakage were cervical (38/46, 82.6%), upper mediastinum (4/46, 8.7%), and all mediastinum with mediastinitis (4/46, 8.7%). The median time of clinical occurrence was 5.6 [2–8] days; moreover, only two cases developed clinical fistula even with a negative result after swallowing X-ray contrast. We did not systematically perform an upper endoscopy to evaluate the size of the defect in the anastomosis; rather, we performed endoscopy for dilatation of the anastomosis in cases after refractory healing after 14 days. We could only estimate the occurrence of proximal necrosis (partial) of the gastric pull-up and anastomosis in four (8.7%) cases and one case (2.1%) of total necrosis of the gastric tube (in a patient with previous liver transplantation).


Anastomosis leakage is still one of the most severe complications after esophagectomy. It increases the mortality, number of days of hospitalization, and the risk of other postoperative complications such as pneumonia, acute respiratory distress syndrome, cardiac arrhythmia, renal failure, sepsis, and others. The mortality rate related to anastomosis dehiscence has decreased in recent years thanks to improved surgical techniques, interventional radiology (percutaneous drainage), the use of minimally invasive techniques and better selection of patients (4). Kamarajah et al. demonstrated that patients with anastomotic leak were associated with a significantly longer stay in critical care and also longer hospitalization time, but they do not have compromised long-term outcomes and are unlikely to have a detrimental oncological impact (5). Identifying the risk factors for esophageal leak may help to decrease post operatory morbidity and mortality or better optimize patients to reduce the postoperative complications.

A range of patient related factors and systemic variables can influence anastomotic leak. Edmund et al reviewed 7,595 esophagectomies and identified a global anastomosis leak rate (including thoracic and cervical anastomoses) of 10.6%. The main risk factors for anastomosis leak are in most cases associated with gastric tube’s perfusion. Obesity, heart failure, coronary heart disease, vascular disease, preoperative malnutrition, hypoalbuminemia, hypertension, steroids, diabetes, kidney failure, smoking, duration of the procedure greater than 5 hours, and type of procedure (transhiatal approach/cervical anastomosis) were considered risk factors for anastomosis leak. The rate of cervical anastomotic leak was higher than intrathoracic probably due to the lower perfusion of the cervical anastomosis (6). However, it is worth mentioning that despite the higher transhiatal rate of cervical anastomosis leak than transthoracic, the mortality rate comparing transhiatal and the Ivor Lewis anastomosis were statistically similar (7). The actual management of anastomotic leaks (percutaneous drainage, endoscopy vacuum, minimally invasive surgery and intensive care) has improved the morbidity and mortality of the intrathoracic leak.

Other important factors associated with anastomosis leaks as studied by Juloori and colleagues is the influence of preoperative radiation fields on postoperative leak rates in esophageal cancer. They found that anastomosis placed within the preoperative radiation field was a very strong predictor for anastomotic leaks (8).

Markar et al. published a systematic review and meta-analysis to analyze the main technical parameters that impact anastomotic integrity; cervical anastomosis was the only factor analyzed that increased the risk of leak. The choice of the anastomosis technique (hand-sewn versus stapled esophagogastric anastomosis), the surgery approach (minimally invasive versus open esophagectomy), and the route of reconstruction (Anterior Versus Posterior Mediastinal Reconstruction) were not risk factors for anastomosis leak (9). This suggests that the longer distance that the blood supply must travel for anastomotic healing in the neck compared with an intrathoracic approach is correlated with a greater chance of leak. Another important fact that seems to correlate with the chance of anastomotic leak is the anastomosis’s perfusion and the patient’s clinical comorbidities (which are also indirectly related to anastomosis vascularization). There is no statistical difference in the anastomotic leakage rate in cervical and transthoracic cases in the benchmark group (patients with low comorbidities) (10).

In this context (perfusion influences cervical anastomosis healing), we developed alternatives that improved the vascularization of the anastomosis. Akiyama et al. used a method called gastric conditioning where they embolized the principal feeding arteries of the stomach (the left and right gastric arteries as well as the splenic arteries weeks before esophagectomy) to allow the gastroepiploic arteries to develop collaterals and reduce the incidence of ischemia of the gastric conduit. However, the leak rates were similar to the others patients (11).

Another interesting strategy is the supercharge techniques in which two vascular anastomoses (microsurgical or not) are performed between an arterial and venous branch of the gastro-omental arch and a neck vessel—usually a branch of the external carotid arteries and external jugular vein. This technique improves the perfusion of the gastric tube and decrease the risks of the anastomosis leakage. Yoshimi et al. had a significantly lower anastomotic leakage in the supercharge group than in the control group (12).

Our institution performs cervical anastomosis systematically. In Brazil, 77% of esophageal carcinoma cases are squamous cell type, and the location of esophagogastric anastomosis is correlated to an extension of the oncological margins. The proximal margin requires cervical location anastomosis after esophagectomy. Huang et al. showed that the extent of radical esophagectomy and lymphadenectomy was better in patients with middle thoracic esophageal cancer who received cervical anastomosis than intrathoracic anastomosis. The cervical anastomosis does not increase mortality; it improved the 5-year survival rate (13). Finally, cervical anastomosis does not worsen the patient’s long-term quality of life. Wormald et al. showed that there was no significant difference between cervical or intrathoracic anastomosis for functional or symptom scores. They focused on overall health score, dysphagia, odynophagia, and swallowing problems (14).


Funding: None.


Provenance and Peer Review: This article was commissioned by the Guest Editor (Alejandro Nieponice) for the series “Anastomotic Techniques for Minimally Invasive Esophagectomy and Endoscopic Handling of Its Complications” published in Annals of Esophagus. The article has undergone external peer review.

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at The series “Anastomotic Techniques for Minimally Invasive Esophagectomy and Endoscopic Handling of Its Complications” was commissioned by the editorial office without any funding or sponsorship. The authors have no other conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. All procedures performed in this study were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patients.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See:


  1. Pinotti HW. Extrapleural approach to the esophagus through frenolaparatomy. AMB Rev Assoc Med Bras 1976;22:57-60. [PubMed]
  2. Transhiatal and transthoracic (thoracoscopy and thoracotomy esophagectomy for squamous-cell carcinoma. In: 10th World congress of the International Society for Diseases of the Esopahgus, 2006, Adelaide. 10th World congress of the International Society for Diseases of the Esopahgus - Congress Handbook. p. 78.
  3. Sallum RAA, Takeda FR, Szachnowicz S, et al. Early and late results of 107 mi esophagectomy for cancer compared to data of lymphadenectomy and late survival in last 40 years. In: 15th World Congress of the International Society for Diseases of the Esophagus - ISDE, 2016, Singapura. Diseases of the Esophagus 2016;29:106A.
  4. Martin LW, Swisher SG, Hofstetter W, et al. Intrathoracic leaks following esophagectomy are no longer associated with increased mortality. Ann Surg 2005;242:392-9; discussion 399-402. [Crossref] [PubMed]
  5. Kamarajah SK, Navidi M, Wahed S, et al. Anastomotic Leak Does Not Impact on Long-Term Outcomes in Esophageal Cancer Patients. Ann Surg Oncol 2020;27:2414-24. [Crossref] [PubMed]
  6. Kassis ES, Kosinski AS, Ross P Jr, et al. Predictors of anastomotic leak after esophagectomy: an analysis of the society of thoracic surgeons general thoracic database. Ann Thorac Surg 2013;96:1919-26. [Crossref] [PubMed]
  7. Ryan CE, Paniccia A, Meguid RA, et al. Transthoracic Anastomotic Leak After Esophagectomy: Current Trends. Ann Surg Oncol 2017;24:281-90. [Crossref] [PubMed]
  8. Juloori A, Tucker SL, Komaki R, et al. Influence of preoperative radiation field on postoperative leak rates in esophageal cancer patients after trimodality therapy. J Thorac Oncol 2014;9:534-40. [Crossref] [PubMed]
  9. Markar SR, Arya S, Karthikesalingam A, et al. Technical factors that affect anastomotic integrity following esophagectomy: systematic review and meta-analysis. Ann Surg Oncol 2013;20:4274-81. [Crossref] [PubMed]
  10. Schmidt HM, Gisbertz SS, Moons J, et al. Defining Benchmarks for Transthoracic Esophagectomy: A Multicenter Analysis of Total Minimally Invasive Esophagectomy in Low Risk Patients. Ann Surg 2017;266:814-21. [Crossref] [PubMed]
  11. Akiyama S, Ito S, Sekiguchi H, et al. Preoperative embolization of gastric arteries for esophageal cancer. Surgery 1996;120:542-6. [Crossref] [PubMed]
  12. Yoshimi F, Asato Y, Ikeda S, et al. Using the supercharge technique to additionally revascularize the gastric tube after a subtotal esophagectomy for esophageal cancer. Am J Surg 2006;191:284-7. [Crossref] [PubMed]
  13. Huang HT, Wang F, Shen L, et al. Clinical Outcome of Middle Thoracic Esophageal Cancer with Intrathoracic or Cervical Anastomosis. Thorac Cardiovasc Surg 2015;63:328-34. [Crossref] [PubMed]
  14. Wormald JC, Bennett J, van Leuven M, et al. Does the site of anastomosis for esophagectomy affect long-term quality of life? Dis Esophagus 2016;29:93-8. [Crossref] [PubMed]
doi: 10.21037/aoe-21-11
Cite this article as: Takeda FR, Sallum RAA, Fernandes FA, Cecconello I. McKeown—cervical anastomosis in minimally invasive esophagectomy. Ann Esophagus 2022;5:23.
