Robot-assisted hand-sewn intrathoracic anastomosis after esophagectomy

Eline M. de Groot^, Feike B. Kingma, Lucas Goense, Sylvia van der Horst^, Jan Willem van den Berg, Richard van Hillegersberg^, Jelle P. Ruurda^

Department of Surgery, University Medical Center Utrecht, Utrecht, The Netherlands

Contributions: (I) Conception and design: EM de Groot, FB Kingma, JP Ruurda, R van Hillegersberg; (II) Administrative support: EM de Groot; (III) Provision of study materials or patients: R van Hillegersberg, JP Ruurda, JW van den Berg, S van der Horst; (IV) Collection and assembly of data: EM de Groot; (V) Data analysis and interpretation: All authors; (VI) Manuscript writing: All authors; (VII) Final approval of manuscript: All authors.

^ORCID: Eline M. de Groot, 0000-0001-9951-8165; Sylvia van der Horst, 0000-0002-3185-8902; Richard van Hillegersberg, 0000-0002-7134-261X; Jelle P. Ruurda, 0000-0001-6584-1677.

Correspondence to: Jelle P. Ruurda. Department of Surgery, University Medical Center Utrecht, POBOX 85500, 3508 GA, Utrecht, The Netherlands. Email:

Background: In two-stage minimally invasive esophagectomy (MIE), most surgeons use a stapling device to avoid the challenges of thoracoscopic suturing in the upper mediastinum. However, in robot-assisted minimally invasive esophagectomy (RAMIE), the surgeon benefits from increased dexterity that facilitates the construction of a hand-sewn intrathoracic anastomosis. This study aimed to evaluate the outcomes of a refined technique for the robot-assisted hand-sewn intrathoracic anastomosis in RAMIE, which was introduced in 2016 in our center.

Methods: Patients who underwent RAMIE with a robot-assisted hand-sewn intrathoracic anastomosis between 1 November 2019 and 1 November 2020 were included in the current retrospective study. During this time frame, the technique was uniform and no more refinements were made. Data were extracted from a prospectively maintained database. Main elements of the anastomotic technique included supportive stay-stitches to keep esophageal mucosa to the muscular wall, manual barbed suturing of the posterior and anterior wall, placement of tension releasing stitches and covering of the anastomosis with omentum. The primary outcome was anastomotic leakage and secondary outcomes included the duration of anastomosis construction.

Results: During the inclusion period, 22 patients were included in the study. Anastomotic leakage occurred in 3 patients (14%), which involved a grade I leak in 2 patients (9%) and grade 3 leakage in 1 patient (5%). The total duration of anastomosis construction was 37 minutes (range, 25–48 minutes).

Conclusions: This study shows that a robot-assisted hand-sewn intrathoracic anastomosis can yield good outcomes in RAMIE.

Keywords: Intrathoracic anastomosis; robot-assisted minimally invasive esophagectomy (RAMIE); technique

Received: 17 December 2020; Accepted: 17 February 2021; Published: 25 June 2022.

doi: 10.21037/aoe-20-98


Locally advanced esophageal cancer is mostly treated by chemo(radio)therapy followed by radical esophagectomy with lymphadenectomy (1). After esophagectomy, a gastric conduit reconstruction with an intrathoracic or cervical anastomosis is usually made. Although extensive efforts have been made to identify the optimal anastomotic technique in esophagectomy, the incidence of anastomotic leakage remains about 15–20% (2). Previous studies comparing hand-sewn versus stapled anastomotic techniques have been inconclusive (3-5).

To construct an intrathoracic anastomosis during esophagectomy, a hand-sewn, linear stapled, or circular stapled technique can be applied (6). With the increasing use of minimally invasive surgery and number of surgeons adopting the Ivor-Lewis approach for mid to distal esophageal tumors, a stapled anastomosis has become the standard of care for conventional minimally invasive esophagectomy (MIE) (7). However, articulating robotic instruments improve the surgeon’s dexterity and facilitate the construction of a hand-sewn intrathoracic anastomosis in robot-assisted minimally invasive esophagectomy (RAMIE). In our center, this technique was introduced in 2016 and refined during the subsequent years (8). The aim of this study was to describe our current technique and evaluate the outcomes of patients who underwent RAMIE with this type of robot-assisted hand-sewn intrathoracic anastomosis. We present the following article in accordance with the STROBE reporting checklist (available at


Patient population

Patients were selected from a prospectively maintained database of the University Medical Center Utrecht. Patients who underwent a RAMIE with an intrathoracic hand-sewn anastomosis between 1 November 2019 and 1 November 2020 were included in the current retrospective study. A hand-sewn anastomosis was standard of care for all patients who underwent Ivor-Lewis. This inclusion period was chosen because the aim of this study was to evaluate the outcomes of the current anastomotic technique after previously reported refinements (8). This anastomotic technique was uniformly applied throughout the consecutive cases.

The study was conducted in accordance with the Declaration of Helsinki (as revised in 2013). The study was approved by institutional ethical board of the University Medical Center Utrecht (No. 13-061) and the need for informed consent was waived.

RAMIE procedure

All patients underwent fully robotic RAMIE (i.e., robotic surgery during both the abdominal and thoracic phase) with extended two-field lymphadenectomy (including mediastinal stations 2 and 4), gastric conduit reconstruction with intrathoracic anastomosis. The technical steps of the thoracic phase of the RAMIE procedure were described in detail in a previous publication (9). All surgeries were performed by 2 surgeons who have RAMIE experiences since 2003 and 2011 respectively and perform RAMIE procedures with an intrathoracic hand-sewn anastomosis since 2016 and onwards.

Anastomotic technique


For the thoracic phase, the patient was placed in left sided semi-prone position. An 8 mm robotic trocar is inserted in the 6th intercostal space for the camera. The other 3 robotic 8mm trocars were inserted in the 4th, 8th and 10th intercostal space. The assistant port was placed in the 5th intercostal space. For the creation of the intrathoracic anastomosis, robotic arm 1 and 2 were used for the Cadiere and the Vessel Sealer, arm 3 for the camera and arm 4 for the Needle Driver. The assistant port was mainly used for suction and the introduction of sutures.

Location of anastomosis

In general, the anastomosis was constructed at the level, just above the azygos vein, guided by tumor location. 7.5 milligram indocyanine green (ICG) was injected and visualized by fluorescence Firefly technology (Intuitive Surgical Inc., Sunnyvale, CA) to evaluate the vascularization of the gastric conduit and determine the exact anastomotic site at the gastric conduit (Figure 1).

Figure 1 Determining the location of the anastomosis in the gastric conduit with indocyanine green during RAMIE. RAMIE, robot-assisted minimally invasive esophagectomy.

Incision in gastric conduit

The incision is approximately 1–2 centimeters and made with a Cautery Hook parallel to the longitudinal gastric stapler line. The location in relative to this staple line is halfway in the gastric conduit, slightly near the omentum.

Supportive stitches

In order to create an adequate overview of the serosa of the esophagus, 4 supportive stay-stiches were placed in the wall of the esophagus using a Vicryl 4.0.

Suturing anastomotic wall

The anastomosis was performed with an end-to-side construction (Figure 2). A barbed V-Loc 4.0 suture was used to close the posterior wall by a single-layer running hand-sewn technique. The space between the bites was aimed to be around 5mm. In a similar way, the anterior wall was sutured with a separate barbed V-Loc 4.0. When the anastomosis was almost closed, a nasogastric tube was inserted and positioned under vision. The sutures were secured by sewing the V-Loc in backward direction.

Figure 2 Closure of the posterior and anterior wall of the anastomosis during RAMIE with a running barbered suture. RAMIE, robot-assisted minimally invasive esophagectomy.

Tension release stitches

To avoid traction on the running sutures of the anastomosis, 3–4 tension releasing mattress stitches were placed as an overlay to approximate the esophageal wall to the gastric wall (Figure 3). For this step a Vicryl 3-0 suture was used.

Figure 3 The placement of tension releasing stitches to reduce traction on the hand-sewn anastomosis during RAMIE. RAMIE, robot-assisted minimally invasive esophagectomy.

Omental wrap

In all cases an omental wrap was applied. To avoid possible twisting of the gastric conduit, this was not performed in a circular fashion, instead the omentum was only fixed on the anterior wall of the anastomosis. Care was taken to position the gastric conduit in the esophageal bed.

Perioperative management

An enhanced recovery after esophagectomy protocol was used for the postoperative management and did not change during the inclusion period. Generally, all patients received epidural or paravertebral anesthesia. The epidural or paravertebral catheter was removed on postoperative day 3. During surgery, 2 Jackson Pratt drains were inserted bilateral in the thoracic cavity. Only if indicated a large caliber thoracic drain was left behind (i.e., pulmonary damage). The Jackson Pratt drains were usually removed when the production was less than 200 milliliters per 24 hours. The nasogastric tube remained until the contrast imagine was performed at postoperative day 4. The aim of this contrast imagine is to look for delayed gastric emptying and vocal cord dysfunction or aspiration. If this was not the case, the nasogastric tube was removed at postoperative day 4 and the patient could start with water intake. A jejunostomy feeding tube was routinely placed, as oral intake was prohibited until postoperative day 4 and carefully resumed from then onward.


All outcomes were extracted from a prospectively maintained database. The primary outcome was anastomotic leakage defined by the Esophageal Complications Consensus Group (10). Secondary outcomes were length of hospital stay, in-hospital mortality and duration of the anastomosis. The total duration of the anastomosis was defined as the time (minutes) between the incision in the gastric conduit and the omental wrap. The duration of the anastomosis walls was defined as the time (minutes). between the first suture of the posterior wall and the last suture of the anterior wall. All operations were routinely recorded and stored at the hospital server, hence it was possible to review the surgical videos and determine the exact duration of the anastomosis.


Data was analyzed using SPSS 25.0 (IBM). Only descriptive analyses were performed. Continuous outcomes were shown as a median with range or mean with standard deviation, depending on data distribution. Categorical data were shown as numbers with percentages.


Between November 2019 and November 2020, 22 consecutive patients who underwent RAMIE with an intrathoracic hand-sewn anastomosis were included. The patient characteristics and outcomes are shown in Table 1. The total time to complete the anastomosis, measured from the incision in the gastric conduit until the omental wrap was finished, was a median of 37 minutes (range, 25–48 minutes). Closing the posterior and anterior wall took a median of 23 minutes (range, 16–32 minutes). Out of 21 patients, 3 patients developed anastomotic leakage (14%). These cases involved a grade I leak in 2 patients (9%) and a grade III leak in 1 patient (5%). A Grade 1 leak was treated with antibiotics and nil per mouth. The patient with a grade III leak required a reoperation. In-hospital mortality occurred in 1 patient (5%), which was caused by massive aspiration. The median length of hospital stay was 9 days (6-20).

Table 1

Patients’ characteristics and outcomes

Variables Number
   Age, years 66 [39–81]
   ASA classification
    2 11 (50%)
    3 11 (50%)
   Tumor location
    Distal 16 (73%)
    Mid 1 (5%)
    Junction 5 (22%)
   T stadium
    T1b 1 (5%)
    T2 3 (14%)
    T3 17 (77%)
    T4a 1 (5%)
   Neoadjuvant therapy
    Chemoradiotherapy 20 (91%)
    Chemotherapy 1 (5%)
    None 1 (5%)
    R0 22 (100%)
   Lymph node yield 46 [27–72]
   Duration of anastomosis, minutes
    Posterior and anterior wall 23 [16–32]
    Total* 37 [25–48]
   Anastomotic leakage 3 (14%)
    Grade I 2
    Grade II
    Grade III 1
   Mortality 1 (5%)
   Duration of hospital stay, days 9 [6–20]

*, from incision in gastric conduit till the omental wrap was finished.


This study described the current technique of an intrathoracic hand-sewn anastomosis in RAMIE, which was developed in our center. After several years of refining the technique, an anastomotic leakage rate of 14% was observed in our most recent case series. Hence, the currently presented technique seems safe and reliable to construct an intrathoracic anastomosis in RAMIE.

The incidence of anastomotic leakage after esophagectomy varies widely in literature, with the general range being 10–30% (2,11). Nonetheless, recent multicenter studies suggest that an anastomotic leakage rate of 10–20% is realistic for expert centers (2,12,13). A recent multicenter study by the Upper GI International Robotic Association (UGIRA), which investigated the outcomes of 856 RAMIE procedures in 20 international centers, reported an overall anastomotic leakage rate of 20% (14). In that cohort, a 33% anastomotic leakage rate in a subgroup of 151 patients who received an intrathoracic robot-assisted hand-sewn anastomosis was observed. These initial data come mainly from centers in their learning curve of the technique. However, more recently most UGIRA centers switched to a stapled anastomotic technique because of unsatisfying initial outcomes with a hand-sewn intrathoracic anastomosis in RAMIE. It should be noted that an initial anastomotic leakage rate of up to 30% was also observed for intrathoracic stapled anastomosis in a multicenter study that investigated the learning curve of surgeons switching from a cervical technique, which decreased to 8% after 119 cases (13). The results from our previous study and current series show that the learning curve of a robot-assisted hand-sewn intrathoracic anastomosis may be comparable and yields acceptable outcomes, with an anastomotic leakage rate of 14% in our latest series, of which only one patient required a re-operation (13).

The hand-sewn robot-assisted anastomosis has several benefits. Foremost, the currently presented technique allows the construction of a fully robotic intrathoracic anastomosis, which does not require the surgeon to step away from the console to the table for the introduction of a circular stapling device through a mini-thoracotomy. The hand-sewn approach does not necessitate the presence of an experienced bedside assistant for the construction of the anastomosis which contributes to the surgeons’ autonomy. Furthermore, a hand-sewn anastomosis allows the surgeon to construct a tailored anastomosis which can be easily adapted to the individual patient, particularly in terms of the anastomotic site, size and the ensuing tension on the anastomosis. Although a hand-sewn anastomosis is harder to standardize than the (semi-)mechanical alternatives, increased control may provide benefits in the hands of an experienced surgeon.

Few studies published in detail on the technique of a robot-assisted hand-sewn anastomosis during RAMIE (15-19) (Table 2). Although the techniques differ substantially, the importance of several technical factors are highlighted universally. One of these factors is the distance between the incision in the gastric conduit and the longitudinal stapler line (16,18). Relative ischemia is an important risk factor for anastomotic leakage, which presumably occurs more often in the tissue directly adjacent to the longitudinal staple line and in the gastric conduit tip (20). The anastomotic site should therefore be selected carefully in order to facilitate creation of the anastomosis in a well vascularized region, possibly aided by fluorescence imaging. Another potentially relevant, yet subjective, factor is the tension on the anastomosis. If the gastric conduit is too elongated and anastomosed without any tension on the anastomosis, a dilated gastric conduit suffering from delayed gastric conduit emptying could be the consequence. On the other hand, if tension on the anastomosis is too high, the tissue might tear resulting in anastomotic leakage. This balance might be found more easily in a hand-sewn anastomosis.

Table 2

Overview of articles reporting on robot-assisted hand-sewn intrathoracic anastomosis during RAMIE

Study Year Patients (n) Technique Anastomotic leakage rate
Cerfolio et al. (18) 2013 16 Double layer, end-to-side 0 (0%)
Trugeda et al. (17) 2014 14 Double layer, end-to-end 4 (29%)
Bongiolatti et al. (16) 2016 8 Single layer, end-to-side 2 (25%)
Egberts et al. (15) 2017 52 Double layer, end-to-end 5 (10%)
Zhang et al. (19) 2018 26 Double layer, end-to-end 2 (8%)

The success of an anastomotic technique is multifactorial making every detail count. However, we consider several refinements as essential contributors to the current technique. Firstly, using tension releasing stitches appears to lead to the right balance of tension on the anastomosis. Secondly, the vascularization of the anastomosis is of importance. Factors such as location in the gastric conduit and type of suture (V-Loc 4.0) have furthermore contributed to our anastomotic technique.

In conclusion, the currently presented technique for robot-assisted hand-sewn intrathoracic anastomosis is safe and feasible for achieving an anastomotic leakage rate of 14% in our most recent cohort of patients who underwent RAMIE. In our experience, the most important technical aspects include the location of the anastomosis and the right balance of tension on the anastomosis.
